CoSF-D-RS-EY-M Low RIN Single Frequency Fiber Laser Module
Connet CoSF-D is a low-noise Single Frequency fiber laser based on Distributed Feedback Bragg Grating (DFB) technology. It has independent intellectual property rights and achieves a stable single-frequency laser output with single longitudinal mode, linear polarization, and narrow linewidth. CoSF-D has extremely low phase and frequency noise and low relative intensity noise (RIN). Connet uses unique packaging technology to ensure low-noise DFB single frequency fiber lasers with excellent wavelength stability.
Connet uses extra-cavity technology to significantly suppress the relative intensity noise (RIN) of the DFB single frequency fiber laser, ensuring that the resonant cavity of the single frequency fiber laser is not disturbed. Thanks to RIN suppression technology, CoSF-D-RS-ER-M's relaxation oscillation peak intensity noise is reduced by more than 30dB.
CoSF-D-RS-EY-M is based on Erbium & Yetterbium co-doped fiber with narrow linewidth (<15kHz) and low phase noise, low relative intensity noise (RIN). The standard wavelength is 1551.12nm, and the optional wavelength range is 1530-1570nm, such as the standard wavelength under the ITU framework. Other wavelengths can be customized according to requirements.
Specifications:
|
Parameter |
Unit |
Specification |
||
|
Min |
Typ. |
Max |
||
|
Part no. |
|
CoSF-D-RS-EY-M |
||
|
Center wavelength |
nm |
1530-1572nm fixed, other specify |
||
|
Output power |
mW |
10 |
50 |
100 |
|
Laser output |
|
CW, Single frequency & Single longitudinal mode |
||
|
Beam quality |
M2 |
- |
1.05 |
1.1 |
|
Linewidth |
kHz |
- |
10 |
15 |
|
RIN peak frequency |
kHz |
600 |
700 |
800 |
|
RIN peak |
dBc/Hz |
-145 |
-140 |
-130 |
|
RIN @10MHz |
dBc/Hz |
- |
-155 |
-150 |
|
Phase noise (1m OPD) |
urad/√Hz |
200@100Hz |
||
|
urad/√Hz |
20@1kHz |
|||
|
urad/√Hz |
2@10kHz |
|||
|
SMSR (50pm resolution) |
dB |
55 |
60 |
- |
|
Output polarization |
|
Linear |
||
|
Polarization extinction ratio (PER) |
dB |
23 |
25 |
- |
|
Output power stability |
% |
- |
- |
±1 |
|
Output isolation |
dB |
50 |
- |
- |
|
Wavelength thermal tuning |
nm |
- |
0.8 |
1.0 |
|
PZT wavelength modulation |
|
Optional |
||
|
Modulation frequency (linear) |
kHz |
DC |
10 |
20 |
|
Modulation wavelength range |
GHz |
- |
>8 |
>10 |
|
Operating temperature |
℃ |
0 |
- |
60 |
|
Storage temperature |
℃ |
-40 |
- |
85 |
|
Power supply |
VDC |
12 |
||
|
Communication interface |
|
RS485 |
||
|
Output fiber type |
|
Panda PM1550 |
||
|
Output fiber length |
m |
> 0.5 |
||
|
Optical connector |
|
FC/APC |
||
|
Dimension |
mm |
145x100x25 |
||
|
Weight |
kg |
<0.5 |
||
Ordering Information:
CoSF-D-RS-EY-M-<-15xx-<PW>-PMF/SMF-PZT-FA
PW: Output power, 10mW is fixed, 50mW and 100mW output power are adjustable
SMF output is upon request, PZT fast modulation is on option. Monitoring output is upon request.
Features:
· Narrow linewidth <15kHz, typically <10kHz
· Low phase noise and frequency noise
· Very low relative intensity noise (RIN)
· Stable single frequency, single polarization output
· No mode-hopping
· Small sized package 145x100x25mm
· High reliability
Applications:
· Distributed optical fiber sensing
· Coherent LiDAR
· Fiber optic hydrophone
· Laser spectroscopy
· Coherent communication
· Gas absorption measurement
· Cold atomic physics
· Other scientific research
